Monopoliee

International Hellenic University (IHU) Themed Monopoly

PC version page monopoliee.cores.gr

Android version available in the GitHub releases page.

Restrictions

• 2 - 4 players
• WebGL browser support needed for PC version

Setup

Dependencies

1. Unity 2019.3.7

2. MongoDB Community Server (You can do a custom installation and choose only the Server module)

3. NodeJS 10.X (Recommended version: NodeJS 10.18.0 x64)

4. Git

Downloading the project

Navigate to the folder where you want the project to be saved, open a terminal and run the following command

git clone https://gitlab.com/college-resources/monopoliee.git

You may be asked to login to your GitHub account. This is because the project is owned by a private group.

Preparing the API (Backend)

1. Navigate to monopoliee/Backend and run

npm install

If you get any node-pre-gyp ERR! errors during npm install, make sure you have all bcrypt dependencies installed and run npm install again. Windows users can also download our prebuilt bcrypt package and extract it inside Backend/node_modules. After installing it, run npm install to make sure everything is fine.

Preparing the UI (Unity)

1. Open Unity Editor and open the monopoliee/Unity folder, as a Unity Project.

2. Go to File -> Build Settings and select all scenes in Scenes to build

3. Select WebGl in Platform and click the Switch Platform button, if you don't see a Unity icon next to WebGL.

4. If Development Build is checked, uncheck it.

5. Click Build. (Depending on your setup, building may take ages to complete)

API Documentation

Authentication API

Endpoint	Method	Parameters	Returns	Description
/auth/register	POST	username: String password: String	Redirect to /auth/session	Registers new user
/auth/login	POST	username: String password: String	Redirect to /auth/session	Logs user in
/auth/session	GET	none	User Object	Returns current logged in user
/auth/logout	GET	none	Success message	Logs current logged in user out

Game API

Endpoint	Method	Parameters	Returns	Description
/game/new	POST	seats: Int	Game Object	Creates a new game with seats number equal to seats and joins it
/game/join	POST	game_id: MongoId	Game Object	Joins the game that has _id equal to game_id
/game/list	GET	none	Array of Game Objects	Returns the list of games with status waitingForPlayers or running
/game/current	GET	none	Game Object	Returns the game that the logged in user is currently playing
/game/prices	GET	none	Prices Object	Returns the prices object from config.json

Player API

Endpoint	Method	Parameters	Returns	Description
/player/roll-dice	GET	none	Dice object	Rolls the dice, moves the player and returns the roll
/player/end-turn	GET	none	Player Object	Completes the turn of the current user and returns the next player

Transaction API

Endpoint	Method	Parameters	Returns	Description
/transaction/buy-current-property	GET	none	Property Object	Buys the property that the player is standing on

Socket.io Events

Game Events

• gameIsStarting
• gameLobbyTimer
• gameStarted
• gameEnded

Player Events

• playerJoined
• playerDisconnected
• playerLeft
• playerRolledDice
• playerMoved
• playerTurnChanged
• playerPlaysAgain
• playerPassedFromGo
• playerGotPaid
• playerPaid
• playerBalanceChanged
• playerSteppedOnChance
• playerSteppedOnCommunityChest
• playerSteppedOnTax
• playerGotJailed
• playerGotFurloughed

Property Events

• propertyOwnerChanged
• propertyMortgagedChanged
