This repository contains a hierachical multi-robot global planner that generates paths for a team of Unmanned Aerial Vehicles (UAVs). If you use this code in your academic work, please cite (PDF):
@inproceedings{bartolomei2020multi,
title={Multi-robot Coordination with Agent-Server Architecture for Autonomous Navigation in Partially Unknown Environments},
author={Bartolomei, Luca and Karrer, Marco and Chli, Margarita},
booktitle={2020 {IEEE/RSJ} International Conference on Intelligent Robots and Systems ({IROS})},
year={2020}
}
This project is released under a GPLv3 license.
This repository contains all the instructions to install and run the multi-robot planning pipeline described in the paper above. In particular, the pipeline is composed of many different components that run either on the server or on the agents.
On the server side, the main components are:
Onboard each agent, the main components are:
- Client-server version of VINS-Mono - link
- Local Obstacle avoidance - this repository
The experiences collected by all the agents are sent to the central server, where an optimization-based pose-graph backend fuses all of them. The backend generates a globally consistent map of the navigation environment and localizes the agents in it. This map is used by the global planner, that coordinates the motions of the robots navigating them towards the respective goal positions.
Install Ubuntu 18.04 and ROS Melodic. Install these dependencies:
$ sudo apt install git libv4l-dev libsuitesparse-dev libnlopt-dev
$ sudo apt install python-catkin-tools python-wstool ros-melodic-joy ros-melodic-octomap-ros protobuf-compiler libgoogle-glog-dev ros-melodic-mav-msgs ros-melodic-mav-planning-msgs ros-melodic-sophus ros-melodic-hector-gazebo-plugins ros-melodic-pcl-ros ros-melodic-pcl-conversions libatlas-base-dev python-matplotlib python-numpy ros-melodic-mavros ros-melodic-mavros-extras
$ sudo apt install liblapacke-dev libode6 libompl-dev libompl12 libopenexr-dev libglm-dev
$ sudo apt install clang-format
Create a catkin_ws folder:
$ mkdir -p catkin_ws/src
$ cd catkin_ws
Set-up the workspace:
$ source /opt/ros/melodic/setup.bash
$ catkin init
$ catkin config --extend /opt/ros/melodic
$ catkin config --cmake-args -DCMAKE_BUILD_TYPE=Release
$ catkin config --merge-devel
Clone the dependencies:
$ cd ~/catkin_ws/src
$ git clone [email protected]:VIS4ROB-lab/multi_robot_coordination.git # Https: git clone https://github.com/VIS4ROB-lab/multi_robot_coordination.git
$ wstool init
$ wstool merge multi_robot_coordination/dependencies_ssh.rosinstall # To clone with https: multi_robot_coordination/dependencies_https.rosinstall
$ wstool up -j8
Remove the useless packages:
$ touch mav_control_rw/mav_linear_mpc/CATKIN_IGNORE
$ rm -rf ewok/catkin_simple/
$ rm -rf ewok/mav_comm/
$ rm -rf ewok/rotors_simulator/
Finally, build the workspace:
$ cd ~/catkin_ws
$ catkin build
Once the building is complete, source the workspace:
$ source devel/setup.bash
In the following, we illustrate how to run two experiments. In the first one, the Gazebo Powerplant world is used, while in the second one we show how to reproduce the experiments of the paper.
In this experiment, three robots have to cover a list of user-defined waypoints in the RotorS Powerplant Gazebo model. In this case, the state estimates are provided by Gazebo and the pose-graph back-end will not be utilized. This experiment is meant to test and showcase the global planner.
First, start the simulation with:
$ roslaunch multi_robot_simulation mav_sim_powerplant_three.launch
Once the simulation is started and the UAVs have been spawned, it is possible to start the global planner and the local planners for all the agents in separate terminals:
$ roslaunch multi_robot_global_planner mrp_global_planner_powerplant.launch
$ roslaunch agent_local_planner agent_local_planner.launch agent_id:=0
$ roslaunch agent_local_planner agent_local_planner.launch agent_id:=1
$ roslaunch agent_local_planner agent_local_planner.launch agent_id:=2
To start the experiments, call the service rosservice call /multi_robot_global_planner/plan "{}". It is possible to change the waypoints for the agents in the file multi_robot_global_planner/cfg/waypoints/waypoints_powerplant.yaml.
In this section we show how to run the experiments reported in the paper in a photo-realistic environment using Gazebo. The model that will be used is the abandoned Chemical Plant in Rüdersdorf. A complete 3D model of the plant is available here - all credits go to the original author.
In order to import the model in Gazebo, follow these instructions, after having installed ROS and Gazebo and cloned this repository in a valid catkin workspace.
$ cd ~/catkin_ws/src/multi_robot_coordination
$ cp resources/chemical_plant.tar.xz ~/.gazebo/models # Copy to Gazebo models folder
$ cd ~/.gazebo/models/
$ tar -xvf chemical_plant.tar.xz # Unzip
$ rm chemical_plant.tar.xz # Remove zip file
To test if the model has been properly set, run:
$ roslaunch multi_robot_simulation mav_sim_example.launch world:=chemical-plant run_gazebo_gui:=true
The model will take some time to load. When it is done, you should be able to see the model imported in Gazebo.
Note: a decently powerful PC is required to be able to use this 3D model in Gazebo. If this model is too big, replace it with a smaller one. This website is a good source of models.
Running the experiments with more than one agent is not recommended on a single PC, unless you have a particularly powerful PC (since it would be running visual-inertial odometry, pointcloud filtering, Pose Graph optimization, loop detection, mesh reconstruction and path planning for every agent).
In general, it is recommended to outsource some of the computations to external PCs. In particular, we recommend to run on a central server:
- Pose-graph backend;
- Voxblox mapping;
- Global path planning; and
- Gazebo.
Instead, on the single agents, run:
- Visual-Inertial state estimation (VINS-Mono);
- Local mapping;
- Local path planning; and
- MPC controller.
Here we show how to run the Gazebo simulation on two PCs. Make sure that the two computers are connected to the same network (Wi-Fi or via cable - cable recommended). First, install:
$ sudo apt install net-tools
On the PC where you are going to run the Gazebo simulation, start a roscore. Then, in all the terminals you are going to use, export the ROS_IP and set the ROS Master URI:
$ ifconfig # to get the IP of the first machine -> here ${machine_1_ip}
$ export ROS_IP=${machine_1_ip}
$ export ROS_MASTER_URI=http://${machine_1_ip}:11311/
Then you can start the simulation on the master PC (in this example, for four agents):
$ roslaunch multi_robot_simulation mav_sim_chemical_plant_four.launch
In the second PC, in all the terminals you are going to use, make sure you export ROS_IP of the second machine and the ROS Master URI of the first machine:
$ ifconfig # to get the IP of the second machine -> here ${machine_2_ip}
$ export ROS_IP=${machine_2_ip}
$ export ROS_MASTER_URI=http://${machine_1_ip}:11311/ # Note: machine 1 here!
It is now possible to run other nodes on the two PCs - all the nodes will be connected to the same rosmaster.
In this experiment, we show how to run the complete pipeline in order to perform a full exploration of an area of interest, selected at the beginning of the mission by the user. If multiple PCs are in use, make sure to run the right launch file on the right computer.
First, start the simulation:
$ roslaunch multi_robot_simulation mav_sim_chemical_plant_four.launch
Once the simulation is started (i.e. wait for all the agents to be visible in RViz), it is possible to launch VINS-Mono and the mapping pipeline for every agent. These nodes should run onboard each agent's PC. For the first agent (highest priority is assigned to agent 0):
$ roslaunch multi_robot_simulation vins_sim.launch agent_id:=0
$ roslaunch agent_local_planner agent_mapping_four_sim_0.launch
Repeat the same operation for all the agents, launching the nodes in the respective PCs:
$ roslaunch multi_robot_simulation vins_sim.launch agent_id:=1
$ roslaunch agent_local_planner agent_mapping_four_sim_1.launch
$ roslaunch multi_robot_simulation vins_sim.launch agent_id:=2
$ roslaunch agent_local_planner agent_mapping_four_sim_2.launch
$ roslaunch multi_robot_simulation vins_sim.launch agent_id:=3
$ roslaunch agent_local_planner agent_mapping_four_sim_3.launch
On the server's side, start the pose graph and wait for the initialization to be done:
$ roslaunch pose_graph_backend pose_graph_node_simulation.launch num_agents:=4
It is possible now to launch the path-planning pipeline. On the server's PC:
$ roslaunch multi_robot_global_planner mrp_global_planner_chemical_plant_four.launch
On the agents' PCs, run on the respective PCs:
$ roslaunch agent_local_planner agent_local_planner_sim.launch agent_id:=0
$ roslaunch multi_robot_simulation gps_pose_graph_initializer.launch agent_id:=0
$ roslaunch agent_local_planner agent_local_planner_sim.launch agent_id:=1
$ roslaunch multi_robot_simulation gps_pose_graph_initializer.launch agent_id:=1
$ roslaunch agent_local_planner agent_local_planner_sim.launch agent_id:=2
$ roslaunch multi_robot_simulation gps_pose_graph_initializer.launch agent_id:=2
$ roslaunch agent_local_planner agent_local_planner_sim.launch agent_id:=3
$ roslaunch multi_robot_simulation gps_pose_graph_initializer.launch agent_id:=3
Once the Pose Graph has initialized all the transformations (i.e. when the message GPS covariance: XXX is not printed anymore in the terminal, or when the message Initialized the GPS reference transformation for agent X has been printed for every agent), it is possible to run the experiment. First, initialize MSF for all the agents:
$ rosservice call /firefly_0/pose_sensor_vins_0/pose_sensor/initialize_msf_scale "scale: 1.0"
$ rosservice call /firefly_1/pose_sensor_vins_1/pose_sensor/initialize_msf_scale "scale: 1.0"
$ rosservice call /firefly_2/pose_sensor_vins_2/pose_sensor/initialize_msf_scale "scale: 1.0"
$ rosservice call /firefly_3/pose_sensor_vins_3/pose_sensor/initialize_msf_scale "scale: 1.0"
Then, start the planning:
$ rosservice call /multi_robot_global_planner/plan "{}"
It is possible to trigger the Return-Home behaviour by publishing on the topic:
$ rostopic pub /multi_robot_global_planner/return_home std_msgs/Int16 "data: 0" -1
where you need to put the right agent ID in the data field. If you put -1, all the agents will return home.
In this experiment, we showcase the advantages of the centralized path-planning pipeline, by showing how an agent can re-use the map created by another robot. Notice that, due to the stochasticity of the RRT* planner, it may happen that in some runs one of the agents may not go through the same area mapped by the other UAVs.
First, start the simulation:
$ roslaunch multi_robot_simulation mav_sim_chemical_plant_exp_common_map.launch
Once the simulation is started (i.e. wait for all the agents to be visible in RViz), it is possible to launch VINS-Mono and the mapping pipeline for every agent. These nodes should run onboard each agent's PC. For the first agent:
$ roslaunch multi_robot_simulation vins_sim.launch agent_id:=0
$ roslaunch agent_local_planner agent_mapping_two_sim_0.launch
Repeat the same operation for the other agent:
$ roslaunch multi_robot_simulation vins_sim.launch agent_id:=1
$ roslaunch agent_local_planner agent_mapping_two_sim_1.launch
On the server's side, start the pose graph and wait for the initialization to be done:
$ roslaunch pose_graph_backend pose_graph_node_simulation.launch num_agents:=2
It is possible now to launch the path-planning pipeline. On the server's PC:
$ roslaunch multi_robot_global_planner mrp_global_planner_chemical_plant_exp_common_map.launch
On the agents' PCs, run on the respective PCs:
$ roslaunch agent_local_planner agent_local_planner_sim.launch agent_id:=0
$ roslaunch multi_robot_simulation gps_pose_graph_initializer.launch agent_id:=0
$ roslaunch agent_local_planner agent_local_planner_sim.launch agent_id:=1
$ roslaunch multi_robot_simulation gps_pose_graph_initializer.launch agent_id:=1
Once the Pose Graph has initialized all the transformations (i.e. when the message GPS covariance: XXX is not printed anymore in the terminal, or when the message Initialized the GPS reference transformation for agent X has been printed for every agent), it is possible to run the experiment. First, initialize MSF for all the agents:
$ rosservice call /firefly_0/pose_sensor_vins_0/pose_sensor/initialize_msf_scale "scale: 1.0"
$ rosservice call /firefly_1/pose_sensor_vins_1/pose_sensor/initialize_msf_scale "scale: 1.0"
Then, start the planning:
$ rosservice call /multi_robot_global_planner/plan "{}"
It is possible to trigger the Return-Home behaviour by publishing on the topic:
$ rostopic pub /multi_robot_global_planner/return_home std_msgs/Int16 "data: 0" -1
where you need to put the right agent ID in the data field. If you put -1, all the agents will return home.
In the last experiment, we show the performace of the global planner when three agents have to navigate in the same area of interest. First, start the simulation:
$ roslaunch multi_robot_simulation mav_sim_chemical_plant_three_twist.launch
Once the simulation is started (i.e. wait for all the agents to be visible in RViz), it is possible to launch VINS-Mono and the mapping pipeline for every agent. These nodes should run onboard each agent's PC. For the first agent:
$ roslaunch multi_robot_simulation vins_sim.launch agent_id:=0
$ roslaunch agent_local_planner agent_mapping_three_sim_0.launch
Repeat the same operation for all the agents, launching the nodes in the respective PCs:
$ roslaunch multi_robot_simulation vins_sim.launch agent_id:=1
$ roslaunch agent_local_planner agent_mapping_three_sim_1.launch
$ roslaunch multi_robot_simulation vins_sim.launch agent_id:=2
$ roslaunch agent_local_planner agent_mapping_three_sim_2.launch
On the server's side, start the pose graph and wait for the initialization to be done:
$ roslaunch pose_graph_backend pose_graph_node_simulation.launch num_agents:=3
It is possible now to launch the path-planning pipeline. On the server's PC:
$ roslaunch multi_robot_global_planner mrp_global_planner_chemical_plant_three_twist.launch
On the agents' PCs, run on the respective PCs:
$ roslaunch agent_local_planner agent_local_planner_sim.launch agent_id:=0
$ roslaunch multi_robot_simulation gps_pose_graph_initializer.launch agent_id:=0
$ roslaunch agent_local_planner agent_local_planner_sim.launch agent_id:=1
$ roslaunch multi_robot_simulation gps_pose_graph_initializer.launch agent_id:=1
$ roslaunch agent_local_planner agent_local_planner_sim.launch agent_id:=2
$ roslaunch multi_robot_simulation gps_pose_graph_initializer.launch agent_id:=2
Once the Pose Graph has initialized all the transformations (i.e. when the message GPS covariance: XXX is not printed anymore in the terminal, or when the message Initialized the GPS reference transformation for agent X has been printed for every agent), it is possible to run the experiment. First, initialize MSF for all the agents:
$ rosservice call /firefly_0/pose_sensor_vins_0/pose_sensor/initialize_msf_scale "scale: 1.0"
$ rosservice call /firefly_1/pose_sensor_vins_1/pose_sensor/initialize_msf_scale "scale: 1.0"
$ rosservice call /firefly_2/pose_sensor_vins_2/pose_sensor/initialize_msf_scale "scale: 1.0"
Then, start the planning:
$ rosservice call /multi_robot_global_planner/plan "{}"
It is possible to trigger the Return-Home behaviour by publishing on the topic:
$ rostopic pub /multi_robot_global_planner/return_home std_msgs/Int16 "data: 0" -1
where you need to put the right agent ID in the data field. If you put -1, all the agents will return home. Make sure that the area around the starting position of the robots has been mapped and inserted in the Voxblox map.
In case of problems feel free to open an issue on GitHub or to contact the author at lbartolomei (at) ethz (dot) ch.
In the following, we present a short list of common problems:
- OMPL: If there are problems with
OMPL, make sure that theROSversion is not installed:sudo apt remove ros-melodic-ompl. - Simulation Test: If in the experiments the global planner outputs
[MR Global Planner] The map is empty, cannot plan, it means that Voxblox has not received any point cloud from thePose Graphyet. To solve this issue, wait a few seconds and then trigger the global planner again. - Gazebo Simulation: If the simulation is slow, replace the Chemical Plant model with a smaller one. This will require the generation of a new set of waypoints for the agents. This website is a good source of models.
- Return Home: If the planner cannot find the path towards the home position for one agent, it is likely that the home position has not been inserted in the Voxblox map. To solve this issue, make sure that the starting positions of the agents are mapped in Voxblox.
Contributions that help to improve the code are welcome. In case you want to contribute, please adapt to the Google C++ coding style and run bash clang-format-all . on your code before any commit.
