ConsoleMonster

Tables, trees, charts and live dashboards for .NET and PowerShell. ConsoleMonster lays out the screen, fits content to the terminal, and keeps output readable when it goes to a log. The PowerShell cmdlets use the same rendering engine as the C# library.

Website and gallery · Documentation · .NET API · PowerShell commands · Examples and usage guide

Make PowerShell output nicer in one line

Install the module once, then turn the formatting on for the session:

Install-Module ConsoleMonster -Scope CurrentUser
Import-Module ConsoleMonster
Enable-ConsoleFormatting

Files, processes, services, commands, modules, event log records, IP addresses, volumes and dictionaries that reach the console are then shown as ConsoleMonster tables and records. The objects don't change: pipelines into other commands, Format-*, Out-String, redirected output, jobs and remoting keep PowerShell's behaviour. Disable-ConsoleFormatting turns it off again.

Format-Table, Format-List and Format-Wide use PowerShell's formatting unless you explicitly opt into Enable-ConsoleFormatting -Feature FormatCommands. This separate feature is excluded from All; captures, pipelines, files, jobs, remoting and transcripts retain native output. See everyday formatting, module-owned views, Markdown/HTML and clipboard, and terminal links.

To keep it on in every session, print the lines for your profile. The command only prints them and never edits the profile:

Enable-ConsoleFormatting -ProfileSnippet

# ConsoleMonster: nicer default output in every session. Add these lines to C:\Users\you\Documents\PowerShell\Microsoft.PowerShell_profile.ps1
Import-Module ConsoleMonster
Enable-ConsoleFormatting

Format-Console commands

The Format-Console* commands work like Format-Table and Format-List, and take the same -Property lists and calculated properties. fct and fcl are short aliases for Format-ConsoleTable and Format-ConsoleList.

$servers = @(
    [pscustomobject] @{ Name = 'web-01'; Status = 'Running'; Cpu = 12.5; Region = 'Warsaw'; Tags = @('prod', 'dmz') }
    [pscustomobject] @{ Name = 'web-02'; Status = 'Warning'; Cpu = 71; Region = 'Dublin'; Tags = @('prod') }
    [pscustomobject] @{ Name = 'sql-01'; Status = 'Stopped'; Cpu = 0; Region = 'Dublin'; Tags = @() }
)
$servers | Format-Table

Name   Status     Cpu Region Tags
----   ------     --- ------ ----
web-01 Running 12.500 Warsaw {prod, dmz}
web-02 Warning     71 Dublin {prod}
sql-01 Stopped      0 Dublin {}

$servers | Format-ConsoleTable

╭────────┬───────────┬──────┬────────┬───────────╮
│ Name   │ Status    │  Cpu │ Region │ Tags      │
├────────┼───────────┼──────┼────────┼───────────┤
│ web-01 │ ✓ Running │ 12.5 │ Warsaw │ prod, dmz │
│ web-02 │ ▴ Warning │ 71.0 │ Dublin │ prod      │
│ sql-01 │ – Stopped │  0.0 │ Dublin │ —         │
╰────────┴───────────┴──────┴────────┴───────────╯

• Status words get a marker and a colour, including PowerShell's own words (Success, Warning, Error, Information).
• The numbers in a column share the decimals the column needs, so the decimal separators line up.
• Short values (numbers, sizes, booleans, dates, statuses) never wrap. Long text wraps onto at most three lines, and -Wrap shows all of it.
• Identifiers such as Id, Port and ProcessId are never grouped with thousands separators.
• Dates use one format everywhere: yyyy-MM-dd HH:mm in local time, whatever the culture, so they sort and compare the same on every machine. Numbers follow the culture, or -Culture and CONSOLEMONSTER_CULTURE.
• Types with a known view keep their usual columns, and files keep their directory heading:

 Directory: C:\Windows
╭───────┬──────────────────┬─────────┬──────────────╮
│ Mode  │ LastWriteTime    │  Length │ Name         │
├───────┼──────────────────┼─────────┼──────────────┤
│ la--- │ 2026-09-09 07:09 │  352 KB │ notepad.exe  │
│ la--- │ 2026-10-14 02:06 │ 3.32 MB │ explorer.exe │
╰───────┴──────────────────┴─────────┴──────────────╯

One object stays a one-row table, as with Format-Table (a single dictionary is shown as a record, see below). Format-ConsoleList, or Format-ConsoleTable -View Record, shows labelled fields instead:

$servers[0] | Format-ConsoleList

web-01
  Status  ✓ Running
  Cpu     12.5
  Region  Warsaw
  Tags    prod, dmz

Format-ConsoleTree shows an object's structure, Format-ConsoleJson writes JSON through the same rules, Format-ConsoleError shows an error with its location once, and Show-Console picks a view for you.

Arrays, dictionaries and grouping

Arrays in a cell are joined (prod, dmz), and an empty one shows a dash. A dictionary is shown as a record, and a list of dictionaries as a table of their keys:

@{ Name = 'web-01'; Port = 8080; Enabled = $true } | Format-ConsoleTable
@{ Name = 'web-01'; Port = 8080 }, @{ Name = 'web-02'; Port = 8443 } | Format-ConsoleTable

web-01
  Enabled  ✓ yes
  Port     8080
╭────────┬──────╮
│ Name   │ Port │
├────────┼──────┤
│ web-01 │ 8080 │
│ web-02 │ 8443 │
╰────────┴──────╯

-GroupBy puts the rows under labelled rules with their counts. The grouped column is left out, because the heading already names it (-ShowGroupColumn keeps it):

$servers | Format-ConsoleTable -GroupBy Region -Property Name, Status, Cpu

╭──────────────┬───────────┬──────╮
│ Name         │ Status    │  Cpu │
├─ Dublin · 2 ─┼───────────┼──────┤
│ web-02       │ ▴ Warning │ 71.0 │
│ sql-01       │ – Stopped │  0.0 │
├─ Warsaw · 1 ─┼───────────┼──────┤
│ web-01       │ ✓ Running │ 12.5 │
╰──────────────┴───────────┴──────╯

Keep the output

The output reaches every PowerShell consumer: | Out-String, | Out-File, | Select-String and | more get plain lines. On PowerShell 7.2 and later, a command typed at the prompt can also be captured with $x = ..., > file or -OutVariable. Inside scripts and functions, and on Windows PowerShell 5.1, add -AsString to keep the text in a variable. Use -AsWidget to compose a table into a panel or a dashboard, or to export it:

$report = $servers | Format-ConsoleTable -AsString
$servers | Format-ConsoleTable -AsWidget | Export-ConsoleFrame -Path ./servers.html

The command reference has parameters and examples for every cmdlet.

Compose widgets in PowerShell

Every widget is a New-Console* command. Containers take a script block of children, and widgets with items take item commands with the same -Status, -Detail and -Tone parameters everywhere, so no .NET code is needed:

New-ConsoleTree '[bold]evotec.xyz[/]' {
    New-ConsoleTreeNode 'MX' -Status Pass -Detail '2 records' {
        New-ConsoleTreeNode 'evotec-xyz.mail.protection.outlook.com' -Detail 'priority 0'
    }
    New-ConsoleTreeNode 'DMARC' -Status Fail -Detail 'p=none'
} | Write-ConsoleWidget

New-ConsoleLog -Height 4 {
    New-ConsoleLogEntry 'Discovered 4 domain controllers in 2 domains' -Level Info -At 2s
    New-ConsoleLogEntry 'DC02: USN rollback check failed (event 2095)' -Level Error -At 44s
} | Write-ConsoleWidget

PowerShell conventions lists every widget with its cmdlet form, its live update command and its .NET method form.

Choose your starting point

What you need	Start here
Print objects as readable tables	Tables
Compose panels, trees, charts and progress indicators	Widget gallery, with C# and PowerShell examples
Show work from several threads or scripts	Live dashboards and replays
Ask for input or build a terminal screen	Prompts, menus, forms and grids
Replace existing PowerShell formatting	PowerShell guide
Save output or play a run again	Recording and export

The .NET package has no runtime package dependencies. It targets .NET Standard 2.0, .NET Framework 4.7.2, .NET 8 and .NET 10. The module supports Windows PowerShell 5.1 and PowerShell 7. Both are MIT licensed.

Start with C#

Add the package to your application:

dotnet add package ConsoleMonster

Create a table and write it to the terminal:

using ConsoleMonster;
using ConsoleMonster.Widgets;

Table table = new Table { Title = "Servers" };
table.AddColumn(new TableColumn("Name") { IsKey = true });
table.AddColumn(new TableColumn("Region"));
table.AddColumn(new TableColumn("Status"));
table.AddValues("web-01", "Warsaw", "Pass");
table.AddValues("web-02", "Dublin", "Warn");
table.AddValues("web-03", "Dublin", "Fail");

Terminal.Write(table);

Widgets support object initializers, fluent With... / Add... methods, and the factories in ConsoleMonster.Ui. These styles compose the same objects; choose the one that reads best for your application. The fluent methods are compiled into the library, so consuming projects do not need a source generator.

For typed data, start with Table.For(items) and select columns with expressions. For formatted sizes, durations, numbers and status cells, use the built-in cell presenters. The table guide shows both languages and the output at different window widths.

Logging, hosting and a template

Three optional packages build on the zero-dependency core:

• ConsoleMonster.Extensions.Logging: logging.AddConsoleMonster() writes ILogger entries with ConsoleMonster's level tags, timestamps, categories and scopes. Entries go into a running dashboard's log region, and print as plain lines when the output is redirected.
• ConsoleMonster.Hosting: services.AddConsoleDashboard() shows a generic host's hosted services and log live. It stays out of the way when the output is redirected or the app runs as a service.
• ConsoleMonster.Templates: dotnet new consolemonster creates an app with a menu, logging, the host dashboard and native AOT publishing.

Keep long-running work visible

A dashboard combines named widgets with a session that accepts updates while work runs. In PowerShell, the dashboard captures the script's host output, warnings and errors in its log region:

$dashboard = New-ConsoleDashboard -Title 'Deploy' -Gap 1 {
    New-ConsolePanel -Title 'Servers' { New-ConsoleLanes }
    New-ConsolePanel -Title 'Output' -Fill { New-ConsoleLog }
}

'web-01', 'web-02', 'web-03' | Start-ConsoleDashboard $dashboard -Parallel -ThrottleLimit 3 {
    param($Server)

    Update-ConsoleLane -Key $Server -Status Running -Total 3
    1..3 | ForEach-Object {
        Start-Sleep -Milliseconds 300
        Update-ConsoleLane -Key $Server -Result Pass
    }
    Write-Host "$Server deployed"
    Update-ConsoleLane -Key $Server -Complete
}

In C#, build the screen with DashboardBuilder, run it with LiveSession, and post updates through typed widget handles. Handles accept updates from worker threads; the session draws the screen and restores the terminal when it ends. See the live-session guide for a complete C# example, inline progress, replaceable regions and live tables.

Output that fits its destination

ConsoleMonster detects terminal capabilities and adapts the same widgets to the available space and output host.

• Narrow windows: tables hide lower-priority columns and can turn rows into cards. Paths and other long values wrap at useful separators.
• Colour and fonts: 24-bit, 256-colour, 16-colour and uncoloured output; Full, Basic and ASCII glyph sets. Status includes a symbol or word so colour is not the only signal.
• Logs and CI: redirected output uses plain lines. Live sessions narrate progress instead of emitting a moving screen.
• PowerShell hosts: transcripts and the ISE use host output; jobs and remoting use information records. How those records display colour depends on the receiving host.
• Themes and language: built-in dark and light themes, culture-aware formatting and localized built-in labels.

NO_COLOR and the CONSOLEMONSTER_COLOR, CONSOLEMONSTER_GLYPHS, CONSOLEMONSTER_MODE, CONSOLEMONSTER_THEME and CONSOLEMONSTER_CULTURE environment variables let you choose an explicit profile. See capability detection, environment settings and hosts and CI for supported values and host behavior.

Save, replay and test your output

Export widgets and frames as self-contained HTML, SVG or plain text. Record live-session events, then replay them through the dashboard or export an HTML player, animated SVG or asciicast recording. The recording guide explains the formats and their limits.

For automated checks, use an in-memory target instead of a real console. Assert-ConsoleOutput checks PowerShell output, and the .NET testing APIs let you inspect frames and events. The usage guide has complete assertions, export examples and hosting patterns.

Compatibility

Version 2 replaces the 0.0.x module's Spectre.Console and Terminal.Gui wrappers with ConsoleMonster's own rendering engine. The old New-Spectre* and New-Terminal* commands are removed. Use the installation guide and migration guides when updating existing scripts.

Windows PowerShell 5.1 loads one version of an assembly per session. Modules that use ConsoleMonster there must use the same library version; restart the session after an upgrade. PowerShell 7 loads the module's binaries in their own assembly load context.

The .NET 8 and .NET 10 targets are marked AOT compatible. When trimming, disable the object inspector's reflection member source with InspectorOptions.UseReflection = false, or explicitly preserve the members your application inspects. The general-purpose inspection API still emits a trimming warning because its options are chosen at runtime. Suppress that call-site warning only when you have verified your inputs use dictionary, JSON or custom member sources with reflection disabled. Typed tables preserve their public properties; inferred columns use declaration order on managed runtimes and stable alphabetical order when Native AOT does not expose metadata tokens.

CI publishes and runs a native executable on .NET 8 and .NET 10, checking typed and inferred tables, reflection-free dictionary and JSON inspection, and text, HTML and SVG exports. This applies to the .NET library; the PowerShell module runs inside its PowerShell host and is not a standalone Native AOT application.

Build and release

The repository uses PSPublishModule / PowerForge for C# packaging, module generation and coordinated publication. Run these commands from the repository root with PowerShell 7 and PSPublishModule installed:

# Build the NuGet package and PowerShell module together, without signing or installing locally.
./Module/Build/Build-Module.ps1 -RunMode Build -SignModule $false -SkipInstall $true

# Preview the C# package version without building, updating files or publishing.
./Build/Build-Project.ps1 -ConfigurationGateMode Manifest

# Build only the C# package.
./Build/Build-Project.ps1 -ConfigurationGateMode Build

# Sign the assemblies, NuGet package and module, then publish the coordinated release.
./Module/Build/Build-Module.ps1 -RunMode Publish

The coordinated command builds packages before the module, uses the C# package as the shared version source, and publishes in this order: NuGet, PowerShell Gallery, GitHub. Both publishers use the ConsoleMonster-v{version} release identity. GitHub receives the C# release archive and the PowerShell module ZIP, with generated release notes. The release signs the C# assemblies, NuGet package and PowerShell module with the configured certificate.

Publishing needs the configured signing certificate and destination credentials. Credential file paths can be configured in Build/project.build.json; the module script also accepts PowerShellGalleryApiKeyPath and GitHubApiKeyPath. Build mode does not upload packages. Generated packages and coordinated staging are under Artefacts/; module build reports are under Module/Artefacts/.

For development, build the solution and run the .NET and PowerShell suites:

dotnet build ConsoleMonster.sln -c Release
dotnet test ConsoleMonster.Tests/ConsoleMonster.Tests.csproj -c Release --no-build
Invoke-Pester -Path ./Module/Tests

Run Pester 5 in both Windows PowerShell 5.1 and PowerShell 7 after building the module binaries. CI exercises both PowerShell hosts and the .NET Framework 4.7.2 / .NET 8 / .NET 10 test targets. The source module can load development binaries from ConsoleMonster.PowerShell/bin.

Explore the project

• Interactive website: real rendered output, width and colour comparisons, live replays, and examples in both languages.
• Detailed usage guide: rich text, tables, prompts, forms, Pester output, exports and testing APIs.
• C# showcases and PowerShell examples: runnable examples.
• Benchmarks: measured scenarios and their environment.
• Design system: terminal layout, focus, status and interaction conventions.
• Report an issue: include the host, terminal, font, module or package version, and a small reproduction.

ConsoleMonster is maintained by Evotec and distributed under the MIT license.
